Technical Specification

Cylinder quantity: Single cylinder
Finish: Nickel Plating
Body material: Stainless Steel
Thickness of lock body: 2.0mm
Keys: 5 pcs brass standard keys
Extension length: 20mm of dead bolt
Door thickness: 35mm ~ 50mm
Working voltage: 9 ~ 18 VDC
Working current: 350mA
Static current: 15mA
Locking method: By collision
Lock-opening delay time: Automatically lock within 9s if not opened
Operating time: 0.5s
Service life: 500,000 times
Regulated & filtered: 500VDC Voltage
Locking method: Magnetic induction
Surface temp: Low temperature
Advantage: Low noise, low consumption, long life
Holding force: 1000kg
Open ways from outside: keys
Open ways from inside: Rotary knob
Suitable humidity: 0-90%(non-condensing)
Operating temp: -40°C ~ 50°C
